204LF Lead Free Boiler Drain- Less Stuffing Box
204LF Lead Free Boiler Drain- Less Stuffing Box
• Lead Free Brass
• 125 WOG
• Boiler Drain-Less Stuffing Box
• Hose x MIP 1/2" & 3/4"
• 1/2" MIP x 1/2" Solder Inlet
204LF Lead Free Boiler Drain - Less Stuffing Box - Material Specifications
| No. | Part | Material | |||||
|---|---|---|---|---|---|---|---|
| 1 | Wheel Nut | Hot Rolled SAE. 1010R | |||||
| 2 | Name Plate | Aluminum | |||||
| 3 | Handle Wheel | Cast Iron | |||||
| 4 | Stem | Brass C89550 | |||||
| 5 | Bonnet | Brass C89550 | |||||
| 6 | Packing | Rubber Sae No. 1052# | |||||
| 7 | Washer | Stainless Steel 304/306 | |||||
| 8 | Seat Packing | Rubber Sae No. 1052# | |||||
| 9 | Seat Screw | Brass C89550 | |||||
| 10 | Body | Brass C89550 | |||||
Dimensions
| Part # | Size | H | D | L | ||||
|---|---|---|---|---|---|---|---|---|
| 204TF3LF | 1/2” Female | 2.87 | 2.09 | 1.64 | ||||
| 204TF4LF | 3/4” Female | 2.99 | 2.06 | 1.77 | ||||
| 204TM3LF | 1/2” Male | 3.18 | 2.09 | 1.60 | ||||
| 204TM4LF | 3/4” Male | 3.16 | 2.09 | 1.73 | ||||
